Intelligent DMM w RS-232 PC Interface (only $29.95!) (CSI345)Part Number: CSI345
Price: $29.95
Save 32.7%!
464 IN STOCK
An absolutely amazing value on this sophisticated DMM. High quality construction & features you might expect at twice the price! The CSI345 is an autoranging professional measuring instrument with an RS-232C interface & easy to use software to display & store data to any PC with a serial port operating under Windows.
An absolutely amazing value on this sophisticated DMM. High quality construction & features you might expect at twice the price! The CSI345 is an autoranging professional measuring instrument with an RS-232C interface & easy to use software to display & store data to any PC with a serial port operating under Windows.
GENERAL SPECIFICATIONS:
- DISPLAY: DIGITAL AND ANALOG DISPLAY, 3999 COUNTS AND 38 SEGMENTS BAR GRAPH. DIGITS ARE 15mm HIGH.
- DC VOLTAGE: 4/40/400V±0.5%, 1000V±0.8%
- AC VOLTAGE: 4/40/400V±1.2%, 750V±1.5%
- DC CURRENT: 4/40/400mA±1.2%, 10A±2.0%
- AC CURRENT: 4/40/400mA±1.5%, 10A±3.0%
- RESISTANCE: 400/4K/40K/400K/4M ±1.2%, 40M ±3.0%
- CAPACITANCE: 4/400nF ±4.0%
- TEMPERATURE:0~750°C ±3.0%
- hFE: 1~1000
- DIODE TEST
- AUTORANGE AND MANUAL RANGE
- DATA HOLD
- CONTINUITY TEST
- RS232C STANDARD INTERFACE
- BACK LIGHT
- POWER 6F22(9V) x 1
- SIZE: 78 x 186 x 35mm
- WEIGHT: APPROX. 300g
