Hantek DSO5202P-INT 200MHz, 2 Channel Digital Storage Oscilloscope
Free Shipping on Orders over $99!
Use promo code FREESHIPPING at checkout. Some exclusions apply. Learn more.
1 Year Limited Warranty
Ships Same Day!
All orders for in-stock items placed before 12pmMST Monday through Friday, ship same day!
Manuals, Datasheets, and Other Documents
Circuit Specialists is able to offer the Hantek DSO5202P at the lowest price online.
Even at this low price all of our Hantek oscilloscopes are shipped for FREE and supported from the United States.
The Hantek DSO5202P DSO is a digital storage oscilloscope that provides you with superior performance in a compact, affordable design. This digital oscilloscope is loaded with standard features including USB connectivity, 32 automated measurements, limit testing, data loading, and context-sensitive measurement that allows this instrument to help you get more done in less time. With 200MHz of bandwidth and a 1Gig/S sampling rate, no other digital storage oscilloscope offers as much bandwidth and sample rate for the price.
Hantek provides real-time sampling with a minimum of 10X oversampling on all channels, all the time accurately capturing your signals in its 40K record length internal memory. This 2-channels digital oscilloscope also features a clear, detailed 7" color TFT display that includes innovative on screen "Help" system which provides relevant on-screen help at any time simply by pressing the "HELP" button. This feature makes getting used to the capabilities of the Hantek 5202P a snap.
With easy PC connectivity, you can quickly capture, save, and analyze measurements and results by connecting to your PC via the rear-panel USB device port. Simply pull screen images and waveform data into the stand-alone desktop application (Note: USB Flash Drive supports no larger than 4GB size drives.)
Features
The Hantek DSO5000P Series oscilloscopes, covers the bandwidths from 70MHz to 200MHz while providing real-time and equivalent sample rates respectively up to 1GSa/s and 25GSa/s. This DSO5202P model covers 0Hz to 200MHz at 1 GSa/s.
With intuitive menus and easy-to-operate buttons you can access information quickly during measurements. The multifunction knobs and shortcut keys help you save time during use while the Autoset function lets you detect sine and square waves automatically. The Probe Check Wizard guides you through adjusting the probe compensation and setting the probe option attenuation factor.
The DSO5202P (slightly different than the Hantek 5202B featured in the video above) has an onboard Help system with topics covering all of its features. You can use the Help system to quickly display several kinds of information including general information about using the oscilloscope, such as using the Menu; information about specific menus and controls, such as the Vertical Position Control; and advice to solve problems you may come across while using an oscilloscope. Additionally, the Help system offers three methods for you to find the information you want in the format you most prefer: context-sensitive, hyperlinks, or an index.
Hantek DSO5202P Specifications
- 200MHz bandwidth
- 1GSa/s Real Time sample rate
- Large (7.0-inch) color display,WVGA(800x480)
- Innovative on screen HELP system
- Upgraded display and power supply for international markets (What does this mean?)
- Memory Depth: 40K (Why is 40K memory depth more than adequate for 99% of nearly all users applications?)
- Trigger mode: edge/pulse width/line selectable video/slop/overtime etc.
- USB host and device connectivity, standard (note: USB port is NOT intended to be used to recharge cell phones or other usb charged devices.)
- Multiple automatic measurements
- Four math functions, including FFTs standard
- Provides software for PC real-time analysis
For more information, refer to the Hantek DSO5202P Oscilloscope Owners Manual.
ISO image to create a DSP5000P Series CD
