24 Volt Power Supply - 25 Amp Single Output - HF600W-SMF-24

SKU HF600W-SMF-24

Save 25%! Add to cart to see final price.

Sold out
Original price $126.27 - Original price $126.27
Original price
$126.27
$126.27 - $126.27
Current price $126.27

We're sorry, this item is discontinued.

For help finding an alternative product, please call 1-800-528-1417 or email sales@circuitspecialists.com and we'll be happy to assist.

Availability:
Out of stock

600 Watt 24 Volt Power Supply 25 Amps

Mini Size, Single output with switchable AC input

Specifications

600W Single Output M1 Series


Features:

  • Compact size, high reliability
  • AC input range selected by switch
  • Built-in fan speed control
  • Protections: overload/ over voltage/ over temperature/ short circuit
  • 2 years limited warranty
  • Dimensions 246 x 127 x 63.5(mm)

AC input voltage range

90~132/ 180~264VAC selected by switch

Input frequency

47~63Hz

Inrush current

cold start,30A/115V,60A/230V

Input leakage current

?1mA/ 230VAC

Line regulation (full load)

≤±0.5%

Output voltage adjust range

±10%

Output overload protection

105~150%, shut off, re-power on to recover

Output over voltage protection

115~150%, shut off, re-power on to recover

Withstand voltage

I/P -O/P: 3.0KVAC/1min
I/P -F/G: 1.5KVAC/1min
O/P-F/G: 0.5KVAC/1min

Rise time

50ms@full load (typical)

Hold up time

20ms@full load (typical)

Operating temperature

-20°C~+50°C

Safety standards

meet GB4943, UL60950, EN60950

EMC standards

meet GB9254, EN55022 classA

Cooling method

fan

Weight

2.12kg/pcs

Model DC Output Load Regulation Ripple & Noise Efficiency

HF600W-SMF-24 24V/25A 0.5% 150mV 86%
